Ideal Structures Pvt. Ltd., is an Architectural, Civil and Structural consultancy organization based at Madurai.
0452 - 4371487
+91 90470 13208
R.N.Towers, 86A, P.T.Rajan Road
Madurai - 625 002.
An International Standard School at Valliyoor, Designed by Ar. Jyoti Motha. Ideal Structures was involved with Structural Designs and Cost Optimization. The uniqueness of the design (Structural) is the Truss and tiled roof with Insulation. Micro Concrete tiles were rigidly screwed to the Steel rafters which were supported by trusses. The reduction in roof load enhanced the behavior of the structure against Earth Quake loads.
View of a modern Cold Storage facility proposed near Dindigul. The facility also includes Banana Ripening Plant. The facility includes storage facility for all food items including frozen food. The total storage capacity is 10000 MT. The entire facility was planned and designed by Ideal Structures with support from M/s Voltas, Chennai.
Commercial building located at PP Chavadi Madurai. Planned, Designed and Managed by Ideal Structures. Ar. P.R.S. Sivakumar, gave the finishing touches and elevation details. The building has become a land mark and houses several Corporate offices/ Financial Institutions.
A view of the Engineering Block, consisting of Civil Engineering, Mechanical Engineering and Electrical Engineering Departments. The building has two central courtyards open to sky with good landscaping inside. The desing brings good ventilation, lighting and comfort to the class rooms and Labs. The Project was Planned, Designed and Managed by Ideal Structures.
A view of roofing over foot path from Srivarimettu to Tirumala. The project involved survey, planning and design of steel roofing over foot path running throught the jungles of Tirumala for a length of about 2 Kms.The terrain was unpredictable and challenging. The project has to be completed in short span of time. The fabrication and erection was done by M/s Garuda Roofings, Chennai. Ideal Structures completed the job in stipulated time.
Multi Product Cold Storage facility near Delhi, with fruits grading and sorting line. The uniqueness of the Cold storage is that it has Two storeys underground with access provided by ramp and lifts. The entire superstructure above basement is Steel structure with PUF panels. The total capacity of the cold storage is about 10,000 MT.
This is a Multi Speciality Hospital at Ramanathapuram. The building was Designed by Architect P.R.S. Sivakumar. The Hospital has a large lounge and reception at the entrance; Operation Theatres, Consulting rooms, wards with lifts and ramp facilities. Ideal Structures was involved in total Structural design of the Project.
A inside view of the Paper Machine Plant. The capacity of the unit is 300 TPD. The Structure had two Tandem cranes of 60 Ton and 10 Capacity. The entire Structure was done in RCC frame with Coated sheet panelling in First floor and brick panelling in ground floor. The entire layout was planned, designed and supervised by Ideal Structures.
A View of Bannari Amman Apparels Limited, a garment manufacturing facility near Chennai. The campus has a Two Storeyed Administrative Block which is a RCC flat slab Construction. The main working hall is fully airconditioned column free Trussed roofing of about one lakh square foot. The facilities include Labour rest rooms, Canteen, Power House, and Parking areas. Ideal Structures was involved in Structural design of the entire campus. The facility was completed in a record period of time.
Multi Storeyed Ladies Hostel Building at Dindigul. Ideal Structures was involved in the structural design of the Block. Ideal Structures also offered its structural consultancy in execution of the Gents Hostel Block.
This is an automobile ancillary unit situated in Madurai. The clients were an Indo-Japan joint venture company. The floor shop required an RCC roofing with good lighting. Folded plate RCC roofing with ventilators between the troughs were provided. The design provided a well lit floor area.
A view of the Restaurant of Bell Hotels, Madurai Tamil Sangam Road. The Uniqueness of the design is the truss and tiled roof fabricated with steel salvaged from an old construction. The hall provides seating for about 200 persons to dine at a time.
ESIC Four Doctor's Dispensary cum office building at Ambur near Vellore in Tamilnadu. The project is done along with NBCC Ltd, New Delhi. Ideal Structures is involved in total Planning, Design and Management of the project along with NBCC.
Fully export oriented Instant Coffee Factory of Tata Coffee Limited, Theni. The entire campus (except FDC unit) was designed by Ideal Structures.
A Chemical unit near Madurai, manufacturing Metal Powders. The main processing hall had a Steel Mezzanine floor to accommodate a part of processing equipments. The entire layout was planned, designed and Managed by Ideal Structures.
This is a 50,000 Spindle spinning mill. The uniqueness of the project is the spinning hall with 201' 6" span truss. Ideal structures planned, designed and supervised the entire layout, which includes, The Mill, Plant rooms, Staff rest rooms, Canteen, Office blocks, Mini township for the labours and network of roads and drains.
A Bungalow at kodaikanal designed by architect P.R.S.Sivakumar. Site was a sheep terrain. Ideal Structures was involved in structural design and optimization of cutting and filling of the site.
Effluent treatment plan designed for the discharge of 30 lakhs ltr per day. Facility is located within the factory premises at Subburaj mills Thirunelveli.
One of the major biscuits manufacturer factory of Britannia Industries ltd constructed through its sister concern M/S.Manna Foods Pvt Ltd, Madurai.Ideal Structures was involved in the total design of the facility.
2500 mt.tone dry/conventional cold storage facility near Madurai. Ideal Structures was involved with Voltas India Pvt. Ltd., in designing & putting up the facility.
Ideal Structures was involved in designing a studio above the 3rd floor of NAMATHU MGR PRESS in steel structure.
A multi purpose indoor stadium to seat 5000 students at athiyaman college at Hosur.The facility has a 240 ft column free stadium. The roofing was designed with hollow square and Rectanugular steel section is one of the largest indoor stadium in Engineering Colleges.
A Pre Engineer steel building for M/S.Thejo Engineering Ltd. The entire structure was designed with hollow square & Rectangular sections. Apro build chennai were the architect.
Renovation of existing College Buildings and Construction of First floor for ARSD, Dhaulakhan,New Delhi.Ideal Structures was awarded the work and entire facility is being designed as energy efficient structure.
An Educational Building at Tenkasi in Thirunelveli for a prestigious group of educational institution based at Tenkasi.
As 25000 spindle modern spinning mill for Dhivyalaskhmi Textiles Pvt Ltd at Aruppukottai. The Structure has 170ft span column free area.
A press shop for M/S.Sun pressing Pvt Ltd, Madurai for its chennai facility at Poonthamalli, Chennai. The facility has two EOT cranes of 40 tonne capacity moving parallelly.
Thirupathi - Pilgrims relaxing shed at 7th mile Thirumala Thirupathi designed by Ideal Structures
Roofing at top of twin towers of Kozhikodu busstand in Kerala, the structure was designed as Pyramidal space frame by Ideal Structures.
Fish processing and Cold Storage for Baby Marine Eastern Exports Ltd., Kochin at Mandapam, Ramanathapuram District. The facility has IQF line and frozen cold storage for sea food processing.
A Pre-Engineered building for a multipurpose cold storage at Mehsana in Gujarat.
Mutt building for Adhichunchanahari Mahaswamigal at Rameswaram, Ramanathapuram District.
Structure for Solar Power Plant at IIT Madras.
Foot Over Bridge from Thirupathi railway station to Vishnu Shrinivasan at Thirupathi for TTD. Structure was designed as tubular frame structure.
25000 Spindle Spinning Mill for M/S. Geetha spinning Mill Pvt., Ltd., Rajapalayam.
Yarn Packing Hall with 80' lean to framework design using tubular steel structure for Sri Jayajothi & Co Ltd., Rajapalayam
Unit-C of Rajapalayam Mills Ltd., at PACR Road Rajapalayam. This is the 14000 Spindle Mill with Cotton Godown, Canteen and other amenities designed by Ideal Structures.
School Building for Ramana Vidyalaya Matriculation School at Rajapalayam one of the land marks at rajapalayam designed by Ideal Structures.
90' high Modern Rice Mill for Sri Lalitha Devi Rice Mill, Madurai. The entire Structure was designed using builtup columns & Wide trusses concepts.
Apparel Factory at Thirupur for Santosh Garments. Architect for the project was Sri P.R.S Sivakumar. Ideal Str
150' high Multi Level Agglomeration Plant for TATA Coffee Ltd., near Vaigai Dam, Theni.
2000 metric tone per annum Premium Instant Coffee Plant for TATA Coffee Ltd., in Vaigai Dam, Theni
Naganeeranjanam Mandapam infront of the main temple at Thirumala desinged by Ideal Structures.
Kalayana Mandapam at Tuticorin with PT Slab and beams. The building was designed by Architect Anup. Structural design done by Ideal Structures.
